Detail produk:
|
|
| Tempat asal: | Jiangsu, Cina (daratan) |
|---|---|
| Nama merek: | AMAN |
| Sertifikasi: | C E |
| Nomor model: | AML-VD |
|
Syarat-syarat pembayaran & pengiriman:
|
|
| Kuantitas min Order: | 1 Set/set |
| Harga: | US $15,000-20,000 / Sets |
| Kemasan rincian: | standar ekspor karton kayu |
| Menyediakan kemampuan: | 15 Set / Set per Bulan |
|
Informasi Detail |
|||
| Mengetik: | Pelabelan mesin | Kondisi: | Baru |
|---|---|---|---|
| Aplikasi: | Makanan, Minuman, Komoditas, Medis, Kimia, Mesin & Hardware | Jenis Kemasan: | botol |
| Packaging Material: | Plastik, kertas | Otomatis kelas: | Otomatis |
| Jenis didorong: | Listrik | tegangan: | 220V/380V |
| Kekuasaan: | 0.75 KW | Dimension(L*W*H): | 2800mm * 1650mm * 1800mm. |
| Berat badan: | 150 Kg | tinggi label standar: | 10-190 mm |
| Max. keluar dia. Dari Gulungan label: | 370 mm | Batin dia. Gulungan Label yang sesuai: | 76 mm |
| PLC: | Shneider | Layar sentuh: | Shneider |
| sensor label kepala: | Shneider | cocok untuk: | botol bulat dan botol datar |
| Layanan purna jual yang disediakan: | Pusat Layanan di luar negeri tersedia | Pelabuhan: | Shanghai |
| Cahaya Tinggi: | liquid filling machine,water filling machine |
||
Deskripsi Produk
food bottle stainless steel Automatic Sticker Labeling Machine
| NO. | Item | Qty. | Model | Manufactory |
| 1 | Head Labeling | 1PCS | SCHEIDER SERVO | |
| Motor | ||||
| 2 | PLC | 1PCS | A-20MY-40 | SCHEIDER |
| 3 | Touch screen | 1PCS | HMISTU855 | ProfaceSCHEIDER |
| 4 | Conveyer inverter | 1PCS | ATV303H075N4 | SCHEIDER |
| 5 | Conveyer motor | 1PCS | 750W | TAIWAN WANXIN |
| 6 | Conveyor motor | 1PCS | TAIWAN WANXIN | |
| gear box | ||||
| 7 | Conveyor belt | 5.6m | 82.6mm | Sweden |
| 8 | Bottle | 1PCS | 40W | Taiwan Aoli |
| separating Motor | ||||
| 9 | separating Motor | 1PCS | 1-60 | Taiwan Aoli |
| Gear box | ||||
| 10 | Label cutting sensor | 1set | GK14 | SCHEIDER |
| 11 | Bottle sensor | 1set | WLL170-2N192 | OPTEX |
| 13 | AC contactor | 1 | LC1-D2510MN | SCHEIDER |
| 14 | Intermediate relay | 3 | RXM2LB2P7 | SCHEIDER |
| 15 | Power switch | 1 | S-52HM60 | SCHEIDER |
| 16 | Power supply | 1 | DC24V-50 | SCHEIDER |
Specification:
1. Micro computer control.
2. Extra large touch screen, easy operation.
3. Servo motor, high labeling precision under high labeling speed, stable performance.
4. More then 100 sets labeling memory parameters, labeled bottles exchanged fast.
5. This device is made of high class stainless steel and anodized Al.alloy, meet with GMP standard and never get rusty.
6. Labeling speed:46M/min.(be adjustable as demand)
